IP66 Waterproof Smart Locks for Outdoor Doors and Gates
A waterproof smart lock for an exposed door needs a sealed housing, and all the locks on this page are rated IP66: dust-tight and protected against powerful water jets. Our IP66 range covers 10 models and versions for entrance doors, aluminum profile doors, metal gates and double-sided courtyard doors, with SUS304 stainless steel front housings and a working range of −30°C to 70°C.
- IP66 on every model listed
- −30°C to 70°C working range
- Entrance, profile, gate and double-sided
- Battery or rechargeable lithium

All IP66 Smart Locks
Narrow the list by door, lock type, power or app. All models listed have fingerprint, PIN, RFID card and mechanical-key access and a 5 V Type-C emergency input.
All 10 models shown
No model matches all of these choices. Clear one, or send door photos and we will match it for you.
| Model | Door type | Door thickness | Lock body | Power | App versions |
|---|---|---|---|---|---|
| A2 IP66 waterproof lock | Entrance | 40–120 mm | 6068, 4585, Russian 6585 or 6085 mortise | 4 × AA | Local, Tuya or TTLock |
| R2 screenless face lock | Entrance | 50–120 mm | 6068 mortise | 7.4 V, 4,000 mAh lithium | Tuya; 3D face and palm vein |
| A11 profile door lock | Profile door | 40–90 mm | 2585 to 7085 mortise | 1,000 mAh lithium or 4 × AAA | Local; optional Tuya Wi-Fi |
| A6 decorative profile lock | Profile door | 40–90 mm | 2585 to 7085 mortise | 4 × AAA | Local; optional Tuya Wi-Fi |
| R9 automatic profile lock | Profile door | 40–90 mm | 2585 to 7085 mortise | 2,600 mAh lithium | Tuya Bluetooth; optional face version |
| L1 rim gate lock | Gate | 35–65 mm | Surface-mounted rim body | 4 × AA | TTLock Bluetooth or Tuya Wi-Fi |
| A2 Double-Sided | Entrance; Gate | 40–120 mm | 6068 motorized mortise | 5,000 mAh lithium | Tuya Bluetooth |
| A11 Double-Sided | Profile door; Gate | 40–90 mm | 2585 to 7085 mortise | 1,000 mAh lithium | Local; optional Tuya Wi-Fi |
| A6 Double-Sided | Profile door; Gate | 40–90 mm | 2585 to 7085 mortise | 1,000 mAh lithium | Local; optional Tuya Wi-Fi |
| R9 Double-Sided | Profile door; Gate | 40–70 mm | 2585 to 7085 mortise | 2,600 mAh lithium; optional 3,800 mAh | Tuya Bluetooth; optional face version |
For other models, check the IP rating on the relevant model page.
What IP66 Covers, and What It Does Not
IP66 means the housing keeps out dust and powerful water jets. It does not measure corrosion from salt air, UV fading or wear on moving parts. For coastal sites, the screws, strike and finish matter as much as the housing; our corrosion resistance page explains salt spray testing and cleaning.
The rating also depends on fitting. Keep the panel gasket seated, seal unused holes in the door, and make sure water running down the door does not collect at the lock.
We hold an IP test report to IEC 60529 for the models it covers; a copy is available on request, and our quality documents page shows what we share. How a laboratory runs the dust and water tests is explained in our guide to IP ratings for outdoor gate smart locks.
How the Electronics Are Sealed
Water resistance is built in during assembly, before the housing is closed. Sealant is applied over the circuit-board cover and around the motor module inside the panel. On the L1 keypad, the circuit board is potted in compound inside its stainless steel housing. The back cover is then closed and the panel goes on to final inspection. Each IP66 rating applies to the model as tested, and the fitting notes above still apply on site.



Front, Rear and Both Sides
On an entrance door, the inside panel usually stays dry. On a gate, both faces can take rain, so the inside unit, battery cover and cable route need the same care as the outside. For credentials on both sides, see the double-sided smart locks, which also compares single-sided locks and L2, the L1 rim lock version with a keypad on the rear body.
Power on Outdoor Doors
AA and AAA versions use replaceable batteries, while lithium versions use rechargeable packs; follow the charging instructions for the supplied model. The Type-C input is for emergency power, not normal charging. Keep the mechanical key, the Type-C input and the battery compartment reachable after installation.
Frequently Asked Questions
Which IP66 lock suits a metal gate?
L1, if the gate has no room for a mortise body. For gates with a box section, A2 or A11 fit inside the gate edge, and the double-sided models add a panel on the inside face.
Is R2 with a screen also IP66?
No. The R2 screen version is IP55 with a 5,000 mAh battery. The screenless version is IP66 with a 4,000 mAh battery.
Does IP66 mean the lock will not corrode?
No. IP66 is about water and dust getting into the housing. Corrosion depends on the material, finish, fasteners, site and cleaning. See outdoor durability.
Do all outdoor models use the same battery?
No. A2, L1 and A6 use AA or AAA batteries; R2, R9 and the double-sided models use lithium; A11 comes in both versions.
Can you shortlist a model from site photos?
Yes. Send photos of the door or gate from a distance and close up, both faces, the thickness, and whether the site is coastal.
Find an Outdoor Lock for Your Door
Send photos of the door or gate, its thickness, the access you need on each side, the quantity and your market. We will shortlist the IP66 models that fit.
