Mortises and Lock Bodies

Smart Lock Mortises, Lock Bodies and Accessories

The smart lock mortise, or lock body, is the part inside the door that moves the latch and bolt. It decides whether a lock fits the door at all. We supply mortises, strikes, faceplates and fixing kits for our smart locks, for new doors, replacements and spare-part stock, in three families: indoor doors, security doors, and aluminum profile and courtyard doors.

  • Bodies and strikes for our mortise locks
  • Strikes, faceplates and fixing kits
  • Spare parts for repeat orders
  • Matching from photos or drawings
Stainless steel mortise lock bodies with their strikes on dark stone plinths
Families

Choose by Door Type

Basics

Mortise Basics: Backset, Center Distance and Faceplate

Three measurements describe most mortises. Our other pages refer back to these definitions.

  • Backset: the distance from the door edge to the center of the handle spindle. A 45 mm backset puts the handle 45 mm in from the edge.
  • Center distance: the distance between the handle spindle and the key cylinder, measured vertically. Many of our bodies use 85 mm; 6068 uses 68 mm.
  • Faceplate: the plate on the door edge, given as width × length, for example 22 × 240 mm or 24 × 240 mm. It shows the size of the edge cut-out, not the depth of the body.

The four-digit code combines the first two: 4585 means a 45 mm backset with 85 mm center distance, and 2585 a 25 mm backset for narrow profiles. 6068 is the entrance-door body used by A2, R1, R2, R8, G1, G2 and G3, and 60/70 mm means an adjustable latch or deadbolt that sets to either backset. A matching code is a starting point; case depth, spindle size, bolt layout and screw positions must also match.

Components

What Each Part Does

PartWhat it doesWhat to match
Mortise or lock bodyTurns handle, key or motor movement into latch and bolt movementBackset, center distance, case depth, spindle, bolt layout
Strike or keeperReceives the latch, bolt or hook on the frameOpening size, depth, lip, screw holes, door gap
Faceplate or guide plateCovers the door-edge cut-out around the bodyWidth, length, screw centers, openings
Spindle and fixing kitConnects the two panels through the doorDoor thickness, spindle section and length, screws
Clamp or bracketHolds the lock where there is no mortise, such as glass doorsGlass or frame thickness, contact area
Cards and keysCredentials and backup keys for the orderCard type for the app version, key quantity

A faceplate is not a strike: the faceplate sits on the door edge, the strike on the frame. Order both with the body so they match.

Materials differ by part. Our mortise cases and faceplates come in stainless steel versions, while some assemblies also use iron or other materials for functional parts. Each quotation states the material per component, not one grade for the whole assembly.

Matching

The Body Must Match the Smart Lock

A body with the right size can still fail if it does not work with the panel above it. A2 Double-Sided needs its own 6068 motorized mortise; the profile models need narrow bodies whose spindle matches the panel; M1 needs its adjustable deadbolt. Always order the body under the full smart lock model name, so panel and body ship as one set.

Spares

Spare Parts and Repeat Orders

Keep a spare set for each door group in a project: body, strike, spindle and screws, labeled with the lock model and body code. For a replacement without a readable code, send photos of the faceplate, the case from the side, the spindle and cylinder positions and the strike, with a ruler in the picture.

FAQ

Frequently Asked Questions

Are smart lock mortises universal?

No. Two bodies with the same code can differ in case depth, spindle size and bolt layout. Match the body to the lock model and the door.

Is a faceplate the same as a strike?

No. The faceplate sits on the door edge around the body. The strike sits on the frame and receives the latch or bolt.

Can I order a lock body without the smart lock?

Yes, as a spare or for a replacement. Tell us the lock model it goes with, or send photos of the old body.

What if the old body has no readable code?

Send photos of the faceplate, the side of the case, the spindle and cylinder holes and the strike, with rough measurements. That is usually enough to identify the family.

Can accessories be packed with branded locks?

Yes. Bodies, strikes, spare kits and cards can be packed and labeled with your OEM order. See OEM/ODM services.

Get Started

Match a Body to Your Door

Send the smart lock model, photos of the door edge and the old body, the quantity and your market. We will confirm the body, strike and fixing kit.
